WAGO 745-502/006-000 2-Pole PCB Terminal Block with CAGE CLAMP® Connection
Wago
$3.89
PCB terminal block; 16 mm²; Pin spacing 10 mm; 2-pole; CAGE CLAMP; commoning option; 16,00 mm²; gray.
The WAGO component equivalent to 745502006000 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is commonly used in industrial, commercial, and residential electrical installations, offering ease of use and durability.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- CAGE CLAMP
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Tin-plated
- country of origin sales organisation germany:
- PL
- depth:
- 33.4 mm / 1.315 inch
- drilled hole diameter with tolerance:
- 2.2 (+0.1) mm
- fine stranded conductor:
- 0.2 16 mm / 24 6 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 10 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 10 mm
- fire load:
- 0.291 MJ
- flammability class per ul94:
- V0
- height:
- 33.5 mm / 1.319 inch
- height from the surface:
- 27 mm / 1.063 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 320 V
- number of solder pins per potential:
- 4
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 10 mm / 0.394 inch
- pole no:
- 2
- rated current:
- 76 A
- rated current csa use group b:
- 0.416666666666667
- rated current csa use group d:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage csa use group d:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin arrangement:
- Over the entire terminal strip (in-line)
- solder pin dimensions:
- 1.2 x 1.6 mm
- solder pin length:
- 6.5 mm
- solid conductor:
- 0.2 16 mm / 24 6 AWG
- strip length:
- 12 13 mm / 0.47 0.51 inch
- weight:
- 19.175 g
- width:
- 21.7 mm / 0.854 inch
