WAGO 750-415

4-channel digital input; 24 V AC/DC; 20 ms

Technical Data

• Number of digital inputs: 4
• Total number of channels (module): 4
• Type of signal: Voltage
• Type of signal voltage: AC/DC 24 V
• Sensor connection: 4 x (2-conductor)
• Input characteristic: high-side switching
• Input filter (digital): 20 ms
• Input current typ.: 7.5 mA DC; 9.5 mA AC
• Voltage range for signal (0): ˜ +5 VDC; 0 ˜ 5 VAC
• Voltage range for signal (1): 11 ˜ 30 VDC; 10 ˜ 27 VAC
• Max input data width (internal): 4 bit
• System supply voltage: DC 5 V; via data contacts
• Current consumption, system supply (5 V): 10 mA
• Isolation: 500 V system/supply
• Indicators: LED (A-D) green: Status DI 1 ˜ DI 4

Connection Data

• Connection technology: In-/Outputs: 8 x CAGE CLAMP
• Connection type (1): Inputs/Outputs
• Solid conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
• Fine-stranded conductor: 0.08 ˜ 2.5 mm / 28 ˜ 14 AWG
• Strip length: 8 ˜ 9 mm / 0.31 ˜ 0.35 inch

Geometrical Data

• Width: 12 mm / 0.472 inch
• Height: 69.8 mm / 2.748 inch
• Height from upper-edge of DIN-35 rail: 62.6 mm / 2.465 inch
• Depth: 100 mm / 3.937 inch

Mechanical Data

• Type of mounting: DIN-35 rail

Material Data

• Color: light gray
• Housing material: Polycarbonate, polyamide 6.6
• Fire load: 1.478 MJ
• Weight: 48.000 g
• Conformity marking: CE

Environmental Requirements

• Surrounding air (operating) temperature: 0 ˜ 55 C
• Surrounding air (storage) temperature: -40 ˜ 85 C
• Protection class: IP20
• Degree of pollution (5): 2 per IEC 61131-2
• Operating altitude: 0 ˜ 2000 m
• Mounting position: horizontal (standing/lying) or vertical
• Relative air humidity (no condensation): 95 %
• Vibration resistance: 4g per IEC 60068-2-6
• Shock resistance: 15g per IEC 60068-2-27
• EMC immunity to interference: acc. to EN 61000-6-2, marine applications
• EMC emission of interference: acc. to EN 61000-6-4, marine applications
• Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
• Permissible H₂S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
• Permissible SO₂ contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm

Commercial data

• Packaging type: BOX
• Country of origin: DE
• GTIN: 4045454392796
• Customs Tariff No.: 85389099990

.

The WAGO 750 series standard AC/DC digital input slice module (model 750-415) features 4 digital inputs (24Vdc/24Vac) with high-side switching and a 20ms filter, operates with a supply voltage of 5Vdc provided by the system, and includes spring CAGE CLAMP connections. It is designed for DIN-35 rail mounting with a 12mm width, has an IP20 protection rating, and is suitable for ambient temperatures ranging from 0°C to +55°C.
