Description
4-channel analog input; Resistance measurement; Adjustable
View AllClose
Technical Data
- Number of analog inputs: 4
- Total number of channels (module): 4
- Type of signal: Potentiometer positions
- Configurable type of signal: yes
- Sensor connection: 4 x (2-conductor, 3-conductor, 4-conductor)
- Bit width: 4 x 16-bit data; 4 x 8-bit control/status (optional)
- Resolution (over entire range): 0.1 C (over the entire range); 0.01 C (-50 C ... 150 C; Pt1000, Ni1000)
- Conversion time (typ.): 100 ms
- Conversion time: Per channel: 100 ms (2-/4-wire connection), 200 ms (3-wire connection)
- Measuring error (25 C): 0.6 K (Pt100, Pt200, Pt500, Ni100, Ni120); 0.2 K (Pt1000, Ni1000); 0.3 ... 0.7 at resistance measurement
- Measuring current (typ.): 350 A
- Response time (max.): 3 s
- Sensor types: Pt100 (default setting), Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000 (TK6180 + TK5000), Potentiometer 0 Ohm ... 1.2 kOhm, 0 Ohm ... 5 kOhm
- Temperature range: -200 +850 C (Pt100, Pt200, Pt500, Pt1000), -60 +250 C (Ni100, Ni1000), -80 +260 C (Ni120)
- System supply voltage: DC 5 V; via data contacts
- Current consumption, system supply (5 V): 85 mA
- Field supply voltage: DC 24 V (-25 +30 %); via power jumper contacts (power supply via blade contact; transmission via spring contact)
- Isolation: 500 V system/supply
- Number of incoming power jumper contacts: 2
- Number of outgoing power jumper contacts: 2
Connection Data
- Connection technology: In-/Outputs: 16 x Push-in CAGE CLAMP<sup></sup>
- Connection type (1): Inputs/Outputs
- Solid conductor: 0.08 1.5 mm / 28 16 AWG
- Fine-stranded conductor: 0.25 1.5 mm / 22 16 AWG
- Strip length: 8 9 mm / 0.31 0.35 inch
Geometrical Data
- Width: 12 mm / 0.472 inch
- Height: 69 mm / 2.717 inch
- Height from upper-edge of DIN-35 rail: 61.8 mm / 2.433 inch
- Depth: 100 mm / 3.937 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Color: light gray
- Housing material: Polycarbonate, polyamide 6.6
- Fire load: 0.000 MJ
- Weight: 49.000 g
- Conformity marking: CE
Environmental Requirements
- Surrounding air (operating) temperature: 0 55 C
- Surrounding air (storage) temperature: -40 85 C
- Protection class: IP20
- Degree of pollution (5): 2 per IEC 61131-2
- Operating altitude: 0 2000 m
- Mounting position: horizontal (standing/lying) or vertical
- Relative air humidity (no condensation): 95 %
- Vibration resistance: 4g per IEC 60068-2-6
- Shock resistance: 15g per IEC 60068-2-27
- EMC immunity to interference: acc. to EN 61000-6-1, EN 61000-6-2
- EMC emission of interference: acc. to EN 61000-6-3
- Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
- Permissible H<sub>2</sub>S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
- Permissible SO<sub>2</sub> contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4017332448635
- Customs Tariff No.: 85389099990
