SKU:

750-463

UPC:

MPN:

750-463

Condition:

New

Availability:

In our warehouse: 2

color:

Light gray

conformity marking:

CE

connection technology inputs outputs:

8 x CAGE CLAMP

connection type 1:

Inputs/outputs

country of origin sales organisation germany:

DE

data width:

4 x 16-bit data: 4 x 8-bit control/status (optional)

depth:

67.8 mm / 2.669 inch

depth from upper edge of din rail:

60.6 mm / 2.386 inch

emc emission of interference:

Per EN 61000-6-3

emc immunity to interference:

Per EN 61000-6-1: EN 61000-6-2

exposure to pollutants:

Per IEC 60068-2-42 and IEC 60068-2-43

fine stranded conductor:

0.08 2.5 mm / 28 14 AWG

fire load:

0.881 MJ

height:

100 mm / 3.937 inch

housing material:

Polycarbonate: polyamide 6.6

isolation:

500 V system/field

measured current typ:

¤ 350 A

measurement error 25 c:

¤ 0.5 K in temperature range: 30 +150 C

measurement repetition rate 2 channel 2 conductor:

0.63 s

measurement repetition rate standard:

1.1 s

mounting position:

Horizontal (standing/lying): vertical

mounting type:

DIN-35 rail

number of analog inputs:

4

number of incoming power jumper contacts:

2

number of outgoing power jumper contacts:

2

operating altitude:

0 2000 m

packaging type:

Box

permissible h2s contaminant concentration at a relative humidity 75:

10 ppm

permissible so2 contaminant concentration at a relative humidity 75:

25 ppm

pollution degree 5:

2 per IEC 61131-2

power consumption 5 v system supply:

50 mA

protection type:

IP20

relative humidity without condensation:

0.95

resolution over entire range:

0.1 C

response time max:

4 s

sensor connection:

4 x (2-wire)

sensor types:

Pt1000: Configurable: Ni1000, KTY 81

shock resistance:

15g per IEC 60068-2-27

signal type:

Resistance measurement

signal type configurable:

Yes

solid conductor:

0.08 2.5 mm / 28 14 AWG

strip length:

8 9 mm / 0.31 0.35 inch

supply voltage field:

24 VDC (-25 +30 %): via power jumper contacts (power supply via blade contact: transmission via spring contact)

supply voltage system:

5 VDC: via data contacts

surrounding air temperature operation:

0 55 C

surrounding air temperature storage:

-40 85 C

temperature coefficient:

¤ 20 ppm/K

temperature range:

30 +150 C

total number of channels module:

4

vibration resistance:

Per IEC 60068-2-6

weight:

49.664 g

width:

12 mm / 0.472 inch
