8-channel digital output; 24 VDC; 0.5 A; Low-side switching
Technical Data
- Number of digital outputs: 8
- Total number of channels (module): 8
- Type of signal: Voltage
- Type of signal voltage: DC 24 V
- Actuator connection: 8 x (1-conductor)
- Output characteristic: Low-side switching
- Output current per channel: 0.5 A
- Output current: short-circuit-protected
- Switching frequency max.: 2 kHz
- Type of load: resistive, inductive, lamps
- Reverse voltage protection: yes
- Inductive load switch-off energy dissipation W (max.): 0.5 J
- Max output data width (internal): 8 bit
- System supply voltage: DC 5 V; via data contacts
- Current consumption, system supply (5 V): 25 mA
- Field supply voltage: DC 24 V (-25 +30 %); via power jumper contacts (power supply via blade contact; transmission via spring contact)
- Current consumption, field supply (module with no external load): 12 mA
- Isolation: 500 V system/supply
- Indicators: LED (A-H) green: Status DO 1 DO 8
- Number of incoming power jumper contacts: 2
- Number of outgoing power jumper contacts: 2
- Current carrying capacity of the power jumper contacts: 10 A
Connection Data
- Connection technology: In-/Outputs: 8 x CAGE CLAMP<sup></sup>
- Connection type (1): Inputs/Outputs
- Solid conductor: 0.08 2.5 mm / 28 14 AWG
- Fine-stranded conductor: 0.08 2.5 mm / 28 14 AWG
- Strip length: 8 9 mm / 0.31 0.35 inch
Geometrical Data
- Width: 12 mm / 0.472 inch
- Height: 67.8 mm / 2.669 inch
- Height from upper-edge of DIN-35 rail: 60.6 mm / 2.386 inch
- Depth: 100 mm / 3.937 inch
Mechanical Data
- Type of mounting: DIN-35 rail
Material Data
- Color: light gray
- Housing material: Polycarbonate, polyamide 6.6
- Fire load: 1.117 MJ
- Weight: 48.664 g
- Conformity marking: CE
Environmental Requirements
- Surrounding air (operating) temperature: 0 55 C
- Surrounding air (storage) temperature: -40 85 C
- Protection class: IP20
- Degree of pollution (5): 2 per IEC 61131-2
- Operating altitude: 0 2000 m
- Mounting position: horizontal (standing/lying) or vertical
- Relative air humidity (no condensation): 95 %
- Vibration resistance: 4g per IEC 60068-2-6
- Shock resistance: 15g per IEC 60068-2-27
- EMC immunity to interference: acc. to EN 61000-6-2, marine applications
- EMC emission of interference: acc. to EN 61000-6-3, marine applications
- Exposure to pollutants: Per IEC 60068-2-42 and IEC 60068-2-43
- Permissible H<sub>2</sub>S contaminant concentration at a relative humidity <lt/> 75 %: 10 ppm
- Permissible SO<sub>2</sub> contaminant concentration at a relative humidity <lt/> 75 %: 25 ppm
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4045454826406
- Customs Tariff No.: 85371098990
The WAGO 750 series standard DC digital output slice module features 8 digital outputs (24Vdc, 0.5A each) with low-side switching and 1-wire configuration. It operates on a 5Vdc supply voltage provided by the system and includes spring CAGE CLAMP connections for secure wiring. Designed for DIN-35 rail mounting with a 12mm width, it is rated for ambient temperatures ranging from 0°C to +55°C and has an IP20 protection rating. This module is equivalent to the 750536 model.
- configuration options:
- DIP switch
- conformity marking:
- CE
- connection technology:
- Push-in CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 97.8 mm / 3.85 inch
- emc emission of interference:
- EN 61000-6-4
- emc immunity to interference:
- EN 61000-6-2
- fine stranded conductor:
- 0.34 2.5 mm / 22 14 AWG
- fire load:
- 0.000 MJ
- height:
- 94 mm / 3.701 inch
- input current max:
- 50 mA
- input resistance current input:
- ¤ 50
- input resistance voltage input:
- 100 k
- input signal current:
- 0 20 mA: 4 20 mA (calibrated switching)
- input signal type:
- Voltage || Current
- input signal voltage:
- 0 5 V: 1 5 V: 0 10 V: 2 10 V (calibrated switching)
- input voltage max:
- 30 V
- limit frequency:
- 100 Hz / 5 kHz (configurable via DIP switch)
- load impedance current output:
- ¤ 600
- load impedance voltage output:
- 2 k
- mounting type:
- DIN-35 rail
- nominal supply voltage us:
- DC 24 V
- note:
- The 3 (Us+), 7 (Us+), 4 (GND 3) and 8 (GND 3) connections are internally commoned.Current carrying capacity between 3/4 and 7/8 connections: 1 A (max.)
- operating altitude max:
- 2000 m
- output signal current:
- 0 20 mA: 4 20 mA: 0 10 mA: 2 10 mA (calibrated switching)
- output signal type:
- Current || Voltage
- output signal voltage:
- 0 5 V: 1 5 V: 0 10 V: 2 10 V (calibrated switching)
- packaging type:
- Bag
- power consumption at nominal supply voltage:
- ¤ 25 mA
- power supply type:
- 24 VDC
- relative humidity:
- 5 95 % (no condensation permissible)
- solid conductor:
- 0.08 2.5 mm / 28 14 AWG
- step response typ:
- 3.5 ms (100 Hz): 100 s (5 kHz)
- strip length:
- 9 10 mm / 0.35 0.39 inch
- supply voltage range:
- 30 %
- surrounding air temperature operation:
- -25 70 C
- surrounding air temperature storage:
- -40 85 C
- temperature coefficient:
- ¤ 0.01 %/K
- test voltage input output supply:
- AC 2.5 kV: 50 Hz: 1 min
- transmission error max:
- ¤ 0.2 % of upper-range value
- transmission error typ:
- ¤ 0.1 % of upper-range value
- weight:
- 36.800 g
- width:
- 6 mm / 0.236 inch
- zero span adjustment:
- 3% of upper-range value
