Wago

WAGO 750-960

SKU:

750-960

UPC:

MPN:

750-960

Condition:

New

baud rate:

12 Mbit/s (per PROFIBUS specification)

cable glands number:

2

color:

Light gray

communication fieldbus:

PROFIBUS

connectable sheathed cable diameter:

4.5 9.5 mm

connection type:

D-sub 9 plug

connection type 1:

CAGE CLAMP terminal strip with locking slide (218 Series)

country of origin sales organisation germany:

DE

depth:

45 mm / 1.772 inch

fire load:

0.623 MJ

height:

16 mm / 0.63 inch

housing material:

PA66-105-V2

input current:

5 mA

packaging type:

Bag

pole no:

9

protection type:

IP20

relative humidity without condensation:

0.95

solid conductor:

0.08 0.5 mm / 28 20 AWG

strip length:

5 6 mm / 0.2 0.24 inch

supply voltage:

4.75 5.25 VDC

surrounding air temperature operation:

0 60 C

surrounding air temperature storage:

-25 85 C

vibration resistance:

4g per IEC 60068-2-6

weight:

33.400 g

width:

54 mm / 2.126 inch
