WAGO 750-962 INTERBUS fieldbus connector with D-sub male connector, 9-pole
Wago
$95.30
INTERBUS fieldbus connector (OUT); with D-sub male connector; 9-pole.
The WAGO component equivalent to 750962 is a specific type of electronic module used in automation and control systems. It is designed to facilitate the connection and communication between various devices and systems, ensuring efficient data transfer and operational reliability. This component is part of WAGO's extensive range of automation products, known for their high quality and performance in industrial applications.
- baud rate:
- 2 MBd (per INTERBUS specification)
- color:
- Light gray
- communication fieldbus:
- INTERBUS
- connectable sheathed cable diameter:
- 4.5 9.5 mm
- connection type:
- D-sub 9 socket
- connection type 1:
- CAGE CLAMP terminal strip with locking slide (218 Series)
- country of origin sales organisation germany:
- DE
- depth:
- 54 mm / 2.126 inch
- fire load:
- 0.286 MJ
- height:
- 16 mm / 0.63 inch
- housing material:
- PA66-105-V2
- packaging type:
- Bag
- pole no:
- 9
- protection type:
- IP20
- relative humidity without condensation:
- 0.95
- solid conductor:
- 0.08 0.5 mm / 28 20 AWG
- strip length:
- 5 6 mm / 0.2 0.24 inch
- surrounding air temperature operation:
- 0 60 C
- surrounding air temperature storage:
- -25 85 C
- weight:
- 33.100 g
- width:
- 45 mm / 1.772 inch
