WAGO 756-5204/030-020 2m Sensor/Actuator Cable, 3-Pole M8 Angled Female to M8 Angled Male, PUR Jacket
Wago
$28.69
Sensor/actuator cable; fitted on both ends; 3-pole; M8 socket, angled; M8 plug, angled; 2 m.
The WAGO component equivalent to 7565204030020 is a specific part or module used in various applications, likely within the realm of electrical engineering or automation. This component is designed to meet certain technical specifications and standards, ensuring compatibility and functionality within its intended use. It is important for users to verify the exact requirements and compatibility of this component with their systems to ensure optimal performance and integration.
- bending cycles:
- 2 Mio.
- cable connection direction to mating direction:
- 90
- cable connection direction to mating direction 2:
- 90
- cable length:
- 2 m
- connection type:
- M8 socket - M8 Plug
- contact material:
- CuSn
- contact plating:
- CuNi/Au
- country of origin sales organisation germany:
- DE
- drag chain suitability:
- Yes
- fire load:
- 1.498 MJ
- halogen free:
- Yes
- housing material:
- Polyurethane (PUR)
- operating current:
- 0.166666666666667
- operating voltage:
- AC/DC 60 V
- packaging type:
- Box
- pole no:
- 3
- pollution degree 5:
- 3 per VDE 0110
- protection type:
- IP67
- rated surge voltage:
- 1.5 kV
- sheath material:
- Polyurethane (PUR), halogen-free per DIN VDE 0472 Part 815, flame resistant per IEC 332-2, self-extinguishing
- sheathed cable color:
- Black
- sheathed cable diameter:
- 3.9 4.3 mm
- surrounding air operating temperature dynamic:
- -25 +90 C
- surrounding air operating temperature static:
- -50 +90 C
- tightening torque:
- 0.6 Nm
- weight:
- 67.600 g
