WAGO 757-284/000-005 M12 Sensor/Actuator Box, 8-Way, 4-Pole, 5m Cable
Wago
$133.10
M12 sensor/actuator box; 8-way; 4-pole; 5m connecting cable.
The WAGO 757 series passive field connection box is designed for sensor and actuator devices, featuring an LED indicator and 8-port connection capability with 4-pole M12 connectors. It operates on a supply voltage of 10-30Vdc (nominally 12Vdc or 24Vdc) and comes in RAL 7035 gray color. The box includes a 5-meter cable with bare end flying leads and is suitable for screw mounting. It is rated IP68 for protection against dust and water, and can operate in ambient temperatures ranging from -25°C to +80°C. Made from Polyamide (PA) 66, it is halogen-free and meets UL 94 V0 standards, equivalent to model 757284000005.
- bending radius:
- 10 x cable diameter (min.) for flexible application
- cable design:
- Wire cross-section: 0.34 mm: Wire cross-section 2: 1 mm
- connection technology inputs outputs:
- 8 x M12 socket: 4-pole: incl. ground
- connection technology trunk cable:
- 1 x Fixed connecting cable
- contact resistance max:
- 0.01
- country of origin sales organisation germany:
- DE
- current carrying capacity signal connections:
- 0.0833333333333333
- current carrying capacity supply connections:
- 0.375
- depth:
- 152 mm / 5.984 inch
- encapsulation:
- Fully encapsulated with conformal coating (UL 94 V0)
- halogen free:
- Yes
- height:
- 26 mm / 1.024 inch
- housing material:
- PA 66 (UL 94 V0): RAL 7035: silicon and halogen free
- indicators:
- LED (A) yellow: Signal status (1 x per contact): LED (U) green: Sensor/actuator box status
- insulation resistance:
- 1000 M
- length of connecting cable:
- 5 m
- material properties of the connections:
- Contact: CuSn, nickel base-coat plating and 0.8 m gold-plated: Threaded bush: die-cast Zn, nickel-plated: Seal: Viton: 50 mating cycles
- mounting type:
- Screw mount
- note on protection type:
- 72 h at a depth of 1 m under water per EN 60529 in the fully locked position with its plugs or protective caps
- packaging type:
- Box
- pollution degree 5:
- 3 per VDE 0110
- protection type:
- IP68
- rated value of electrical isolation:
- 500 V
- sheath material:
- PUR
- sheathed cable color:
- Black
- sheathed cable diameter:
- 8.2 mm
- shock resistance:
- Per IEC 60068-2-27
- signal characteristic:
- PNP
- strip length:
- 100 mm / 3.94 inch
- supply voltage:
- 10 30 VDC: Rated voltage: 32 V ~ rms
- surrounding air operating temperature dynamic:
- -5 +80 C
- surrounding air operating temperature static:
- -40 +80 C
- surrounding air temperature operation:
- -25 80 C
- vibration resistance:
- Per IEC 60068-2-6
- width:
- 60 mm / 2.362 inch
- wire colors:
- White, green, yellow, gray, pink, red, black, purple, green/yellow, brown, blue
