Wago

Wago 762-3001 Web Panel; 14.5 cm (5.7"); 640 x 480 pixels; 2 x USB, 2 x ETHERNET

SKU:

762-3001

UPC:

MPN:

762-3001

Condition:

New

baud rate:

ETHERNET: 10/100 Mbit/s

brightness:

630 cd/m2

communication:

Web browser (CODESYS2)

conformity marking:

CE

connection technology communication fieldbus:

Modbus TCP: 2 x RJ-45: USB: 2 x USB 2.0 host (type A)

contrast ratio:

12.5006944444444

controls:

Resistive touch panel: 2 capacitive keys: proximity sensor

country of origin sales organisation germany:

DE

depth:

58 mm / 2.283 inch

display:

Resistive touchscreen

display colors:

262,000 colors

display diagonal:

14.5 cm (5.7 Inches)

ethernet protocols:

DHCP || DNS || FTP || FTPS || HTTP || HTTPS || SSH

fire load:

0.000 MJ

front panel:

Anodized aluminum, polyester film

graphics resolution:

(640 x 480) px

hbt half brightness time:

30000 h

height:

163 mm / 6.417 inch

housing material:

Anodized aluminum

indicators:

Three-color LED (red, green, blue)

internal memory flash:

1024 MB

main memory ram:

512 MB

max input current 24 v:

210 mA

memory card type:

MicroSD (max. 2 GB): microSDHC (max. 32 GB)

mounting type:

Clamping elements (included) or VESA mount (4 x M4x8)

note on protection type:

IP65 (front side): IP20 (rear side), per EN 60529

operating power:

5.1 W (max.)

operating system:

Linux

packaging type:

Box

panel cutout w x h:

(157 x 148) mm

processor:

ARM Cortex A8 600 MHz

protection type:

IP65

relative humidity without condensation:

0.9

supply voltage:

24 VDC, SELV (18 31.2 V): with reverse voltage protection

surrounding air temperature operation:

0 55 C

surrounding air temperature storage:

-20 80 C

viewing angle horizontal vertical:

80 / 80

visualization:

Web Visu

weight:

1067.000 g

width:

172 mm / 6.772 inch
