WAGO 769-108/021-000
Wago
$16.24
1-conductor female connector; CAGE CLAMP; 4 mm²; Pin spacing 5 mm; 8-pole; coding finger; Lateral locking levers; 4,00 mm²; gray.
The WAGO 769 X-COM series 1-conductor female plug features a locking lever, 5mm pin spacing, and 8 poles, with a nominal cross-section of 4mm². It supports wire sizes from 0.08mm² to 4mm² or #28AWG to #12AWG and is rated for a current of 32A. The plug is gray, utilizes CAGE CLAMP spring connections, and has a plug-in mounting width of 55.6mm. It is equivalent to the model 769108021000.
- actuation type:
- Operating tool
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- connector connection type:
- For conductor
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- DE
- depth:
- 18.3 mm / 0.72 inch
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fire load:
- 0.464 MJ
- flammability class per ul94:
- V0
- height:
- 45.2 mm / 1.78 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- locking lever:
- Yes
- marking level:
- Side marking
- module width:
- 5 mm / 0.197 inch
- nominal cross section:
- 4 mm
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- pole no:
- 8
- rated current:
- 32 A
- rated surge voltage iii 3:
- 6 kV
- ratings per:
- IEC/EN 61984
- safety information 1:
- According to EN 61984, pluggable connectors without current interrupting capacity must not be mated or unmated when live or under load.
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- strip length:
- 8 9 mm / 0.31 0.35 inch
- weight:
- 26.942 g
- width:
- 55 mm / 2.189 inch
- wiring direction:
- Front-entry wiring
