Wago

WAGO 769-602/001-000

(No reviews yet) Write a Review
SKU:
769-602/001-000
MPN:
769-602/001-000
Condition:
New
actuation type:
Operating tool
color:
Gray
connectable conductor materials:
Copper
connection technology:
CAGE CLAMP
connector connection type:
For conductor
contact type pluggable connector:
Male connector/plug
country of origin sales organisation germany:
PL
depth:
40.2 mm / 1.583 inch
fine stranded conductor:
0.08 4 mm / 28 12 AWG
fire load:
0.139 MJ
flammability class per ul94:
V0
height from the surface:
18.3 mm / 0.72 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
mounting type:
Snap-in foot
nominal cross section:
4 mm
nominal voltage iii 3:
500 V
packaging type:
Box
pin spacing:
5 mm / 0.197 inch
pole no:
2
rated current:
32 A
rated surge voltage iii 3:
6 kV
solid conductor:
0.08 4 mm / 28 12 AWG
strip length:
8 9 mm / 0.31 0.35 inch
weight:
6.617 g
width:
13.6 mm / 0.535 inch
wiring direction:
Front-entry wiring
  • Wago 769-602/001-000
  • Wago 769-602/001-000
$4.19

Description

1-conductor male connector; Snap-in mounting feet; 4 mm®; Pin spacing 5 mm; 2-pole.

The WAGO 769 X-COM series male connector features snap-in mounting feet, 5mm pin spacing, and supports 2 poles with a nominal cross-section of 4mm², accommodating wire sizes from 0.08mm² to 4mm² or #28AWG to #12AWG. It is rated for a current of 32A, comes in gray, and utilizes CAGE CLAMP spring connections. This connector can be mounted on a DIN rail or surface using an accessory snap-in foot mounting and is equivalent to the model 769602001000.
