Wago

WAGO 769-604/006-000

(No reviews yet) Write a Review
SKU:
769-604/006-000
MPN:
769-604/006-000
Condition:
New
Availability:
In our warehouse: 6
actuation type:
Operating tool
color:
Gray
connectable conductor materials:
Copper
connection technology:
CAGE CLAMP
connector connection type:
For conductor
contact type pluggable connector:
Male connector/plug
country of origin sales organisation germany:
PL
depth:
41.7 mm / 1.642 inch
fine stranded conductor:
0.08 4 mm / 28 12 AWG
fire load:
0.389 MJ
flammability class per ul94:
V0
height:
30 mm / 1.181 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
mounting type:
Snap-in flange variant
nominal cross section:
4 mm
nominal voltage iii 3:
500 V
packaging type:
Box
pin spacing:
5 mm / 0.197 inch
pole no:
4
rated current:
32 A
rated surge voltage iii 3:
6 kV
solid conductor:
0.08 4 mm / 28 12 AWG
strip length:
8 9 mm / 0.31 0.35 inch
weight:
16.986 g
width:
34.3 mm / 1.35 inch
wiring direction:
Side-entry wiring
$8.62

Description

X-COM through-panel connector (male); CAGE CLAMP connection; 4-pole; pole spacing 5 mm / 0.197 in; with adjustable snap-in flanges.

The WAGO 769 X-COM series male connector features snap-in flanges, 5mm pin spacing, and supports 4 poles with a nominal cross-section of 4mm². It accommodates wire sizes from 0.08mm² to 4mm² or #28AWG to #12AWG, with a rated current of 32A. The connector is gray in color, utilizes CAGE CLAMP spring connections, and is designed for snap-in mounting. It is equivalent to the model 769604006000.
