WAGO 788-102

(No reviews yet) Write a Review

Write a Review

WAGO 788-102

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

788-102

UPC:

MPN:

788-102

Condition:

New

color:

Gray

connection technology:

Push-in CAGE CLAMP

country of origin sales organisation germany:

CN

depth from upper edge of din rail:

54 mm / 2.126 inch

dielectric strength control load circuit ac 1 min:

6 kVrms

dielectric strength open contact ac 1 min:

1 kVrms

fine stranded conductor:

0.34 2.5 mm / 22 14 AWG

fire load:

0.642 MJ

height:

86 mm / 3.386 inch

input voltage range:

AC/DC 0 250 V

insulation type between adjacent devices of the the same type:

Basic insulation

insulation type control load circuit:

Reinforced insulation (safe isolation)

insulation type load load circuit:

Basic insulation

limiting continuous current:

0.333333333333333

mounting type:

DIN-35 rail

nominal input voltage un:

AC/DC 230 V

note:

Bei den angegebenen technischen Daten handelt es sich um Maximalwerte. Diese knnen durch das verwendete Zubehr eingeschr¤nkt werden.

number of changeover switchover contacts:

2

operating altitude max:

2000 m

overvoltage category:

II

packaging type:

Box

pollution degree:

3

processing temperature:

-25 +50 C

protection type:

IP20

rated voltage:

300 V

relative humidity:

5 95 % (no condensation permissible)

solid conductor:

0.34 2.5 mm / 22 14 AWG

standards specifications:

EN 61010-2-201

strip length:

9 10 mm / 0.35 0.39 inch

surrounding air temperature operation at un:

-40 70 C

surrounding air temperature storage:

-40 80 C

switching voltage max:

AC 300 V

weight:

30.720 g

width:

15 mm / 0.591 inch
