WAGO 788-124 Pack of 25
Wago
$106.50
Accessories for relay modules; Operation status indicator: red.
The WAGO 788 series operation status indicator is designed for control voltage of 115Vac and features plug-in mounting. It has an IP20 protection rating and is equivalent to the model 788124.
- actuation type:
- Operating tool
- type of fuse:
- Flat blade fuse 19.1 x 5.1 x 18.5 mm
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CN
- depth from upper edge of din rail:
- 33.5 mm / 1.319 inch
- design:
- Angled
- fine stranded conductor:
- 0.2 6 mm / 24 10 AWG
- fire load:
- 0.299 MJ
- flammability class per ul94:
- V0
- height:
- 85 mm / 3.346 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Center marking
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 400 V
- note on rated current 1:
- LED power consumption: 4.8 mA
- operation status indicator:
- 24 V
- packaging type:
- Box
- rated current:
- 25 A
- rated current 2:
- 30 A
- rated surge voltage iii 3:
- 6 kV
- ratings note:
- Electrical ratings are given by the fuse and blown fuse indication.
- ratings note 2:
- Blade-style fuses: Observe touch-proof protection for 42 V and higher voltages!
- ratings per:
- IEC/EN 60947-7-3
- solid conductor:
- 0.2 6 mm / 24 10 AWG
- strip length:
- 12 13 mm / 0.47 0.51 inch
- weight:
- 17.626 g
- width:
- 8 mm / 0.315 inch
- wiring direction:
- Front-entry wiring
