WAGO 788-755 pack of 20 solid-state relays, 24 VDC input, 12275 VAC output, 3.5 A continuous current
Wago
$627.60
Basic solid-state relay; Nominal input voltage: 24 VDC; Output voltage range: 12
275 VAC; Limiting continuous current: 3 A; Module width: 12 mm; Module height: 15 mm.
The WAGO 788 series replacement plug-in solid-state relay (SSR) module features a green LED indicator and a 2-wire connection for zero-cross switching. It is a single-pole, single-phase relay with a control voltage range of 10-30Vdc (24Vdc nominal) and an output rated voltage range of 12Vac-275Vac (230Vac nominal). The relay supports a continuous rated current of 3.5A and includes plug-in connections for easy mounting. This module is equivalent to the 788755 model.
- circuit type:
- 2-wire connection || Zero-voltage switching
- country of origin sales organisation germany:
- DE
- depth:
- 29 mm / 1.142 inch
- dielectric strength control load circuit ac 1 min:
- 3.51 kVrms
- fire load:
- 0.000 MJ
- height from the surface:
- 15.7 mm / 0.618 inch
- input voltage range high level:
- DC 10 ª 30 V
- input voltage range low level:
- DC 0 ª 9 V
- inrush current resistive max:
- (AC) 120 A
- limiting continuous current:
- 3.5 A
- mounting type:
- Pluggable module
- nominal input current at un:
- 12 mA
- nominal input voltage un:
- DC 24 V
- nominal output voltage:
- AC 230 V
- note:
- Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.
- output voltage range:
- AC 12 ª 275 V
- packaging type:
- Box
- standards specifications:
- EN 61010-2-201 || EN 61000-6-2 || EN 61000-6-3 || EN 61373
- status indicator:
- Green LED
- surrounding air temperature operation at un:
- -30 ª 80 C
- surrounding air temperature storage:
- -40 ª 100 C
- switching current min:
- 50 mA
- switching frequency:
- 50 Hz / 60 Hz
- turn off time:
- «± 10 ms
- turn on time:
- «± 10 ms
- voltage drop at output max:
- «± AC 1.1 V
- weight:
- 4.000 g
- width:
- 12.7 mm / 0.5 inch
