WMB Multi marking system; Horizontal marking; 1 ... 50 (2x); for terminal block width 5 - 17.5 mm; stretchable 5 - 5.2 mm; 10 strips with 10 markers per card; Consecutive numbers each strip.
The WMB marking card from the WAGO 793 series is a white, stretchable, horizontal marking card with numbers "1-50" and features snap-on mounting. Each card contains 100 labels, organized into 10 strips with 10 labels per strip. It is compatible with 5mm and 5.2mm-wide terminal blocks and is equivalent to the model 7935566.
- color:
- White
- country of origin sales organisation germany:
- DE
- fire load:
- 0.256 MJ
- marker strip width:
- 5 5.2 mm
- marker width:
- 5 mm
- marking:
- 1 50
- marking color:
- Black
- marking direction:
- Horizontal marking
- marking number:
- 2
- marking type:
- Numbers
- packaging type:
- Bag
- pre assembly:
- 10 strips with 10 markers per card
- representation of the imprint:
- Consecutive numbers per strip
- smear resistance:
- EN 60998-1:2004
- uv resistance:
- EN 60068-2-5:2010 Procedure B
- weight:
- 8.408 g
