WAGO 806-208 2-Conductor Female Connector, 8-Pole, Push-in CAGE CLAMP®, 5mm Pitch, 1.5mm², Gray
Wago
$7.05
2-conductor PCB terminal block; 1.5 mm; Pin spacing 5 mm; 8-pole; Push-in CAGE CLAMP
- Compact, 2-conductor PCB connector strips (pinstrip pluggable) with Push-in CAGE CLAMP<sup></sup> connection and screwdriver-actuation
- Push-in termination of solid and ferruled conductors
- Double entries for power supply and potential distribution
- Quick and easy PCB replacement, without disrupting looped-through potentials
The WAGO component equivalent to 806208 is a specific type of electrical connector or terminal block used for various wiring applications. It is designed to provide secure and reliable connections in electrical circuits, ensuring efficient conductivity and safety. This component is commonly used in industrial, commercial, and residential electrical installations, offering ease of use and durability. The equivalent model to 806208 would have similar specifications and functionalities, making it a suitable replacement or alternative for the original part.
- actuation type:
- Operating tool
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Gray
- conductor connection direction to pcb:
- 45
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For PCB
- contact material:
- Copper alloy
- contact plating:
- Tin-plated
- contact type pluggable connector:
- Female connector/socket
- country of origin sales organisation germany:
- PL
- depth:
- 19.8 mm / 0.78 inch
- fine stranded conductor:
- 0.2 1.5 mm / 24 16 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 1 mm
- fine stranded conductor with uninsulated ferrule:
- 0.25 1 mm
- fire load:
- 0.204 MJ
- flammability class per ul94:
- V0
- height:
- 23.3 mm / 0.917 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +105 C
- material group:
- I
- mating direction to the pcb:
- 90
- nominal voltage ii 2:
- 630 V
- nominal voltage iii 3:
- 250 V
- packaging type:
- Box
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 8
- rated current:
- 0.416666666666667
- rated current csa use group b:
- 0.416666666666667
- rated current ul use group b:
- 0.416666666666667
- rated current ul use group d:
- 0.416666666666667
- rated surge voltage ii 2:
- 4 kV
- rated surge voltage iii 2:
- 4 kV
- rated surge voltage iii 3:
- 4 kV
- rated voltage csa use group b:
- 300 V
- rated voltage iii 2:
- 320 V
- rated voltage ul use group b:
- 300 V
- rated voltage ul use group d:
- 300 V
- ratings per:
- IEC/EN 60664-1
- solder pin diameter:
- 1 mm
- solid conductor:
- 0.2 1.5 mm / 24 16 AWG
- strip length:
- 9 10 mm / 0.35 0.39 inch
- weight:
- 10.212 g
- width:
- 41.5 mm / 1.634 inch
