WAGO 806-912 Board-to-Board Link 12-Pole Connector
Wago
$3.51
THT male header; straight; Pin spacing 5 mm; 12-pole; black.
The WAGO component equivalent to 806912 is a specific part or module used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, often utilized in various industrial applications. This component ensures secure and stable connections, contributing to the overall performance and safety of the system in which it is integrated.
- color:
- Black
- connector connection type:
- For PCB
- contact type pluggable connector:
- Male connector/plug
- country of origin sales organisation germany:
- DE
- depth:
- 2.7 mm / 0.106 inch
- drilled hole diameter with tolerance:
- 1.3 (+0.05) mm
- fire load:
- 0.000 MJ
- height:
- 12 mm / 0.472 inch
- mating direction to the pcb:
- 90
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 5 mm / 0.197 inch
- pole no:
- 12
- solder pin diameter:
- 1 mm
- solder pin length:
- 3.4 mm
- suitable:
- Pin spacing: 5 mm / 0.197 inch
- weight:
- 1.700 g
- width:
- 59.8 mm / 2.354 inch
