Wago 811-330 Fuse terminal block
- SKU:
- 811-330
- Condition:
- New
- actuation type:
- Operating tool
- type of fuse:
- Cylindrical fuse 10 x 38 mm
- color:
- Light gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- CN
- depth from upper edge of din rail:
- 55 mm / 2.165 inch
- design:
- Horizontal type
- fine stranded conductor:
- 2.5 16 mm / 16 6 AWG
- fire load:
- 0.000 MJ
- height:
- 105 mm / 4.134 inch
- insulation material:
- Polyamide (PA66)
- mounting type:
- DIN-35 rail
- nominal voltage iii 3:
- 690 V
- packaging type:
- Box
- pole no:
- 3
- rated current:
- 32 A
- rated voltage iii 3 2:
- 1000 V
- ratings note:
- Electrical ratings are given by the fuse.
- ratings per:
- IEC/EN 60947-7-3
- solid conductor:
- 2.5 16 mm / 14 6 AWG
- strip length:
- 12 13 mm / 0.47 0.51 inch
- weight:
- 200.000 g
- width:
- 52.5 mm / 2.067 inch
- wiring direction:
- Side-entry wiring
On Sale
Description
2-conductor fuse holder ; for cylindrical fuses 10 x 38 mm; 13/32" x 11/2"; 3-pole; without blown fuse indication; 750 VAC/ 1000 VDC; for DIN-rail 35 x 15 and 35 x 7.5; 16 mm²; CAGE CLAMP; 16,00 mm²; light gray
