WAGO 812-102

SKU:

812-102

UPC:

MPN:

812-102

Condition:

New

actuation type:

Operating tool

color:

Dark gray

connectable conductor materials:

Copper

connection technology:

Push-in CAGE CLAMP

country of origin sales organisation germany:

PL

depth:

27.5 mm / 1.083 inch

fine stranded conductor:

0.5 4 mm / 20 12 AWG

fire load:

0.823 MJ

height:

30 mm / 1.181 inch

insulation material:

Polyamide (PA66)

legend ratings:

(III / 3) Overvoltage category III / Pollution degree 3

nominal voltage iii 3:

1000 V

note on rated current 1:

Current carrying capacity: With a maximum total current of 96 A, the clamping units of the busbar terminal block can be loaded with the rated current of the conductor cross-sections approved. This only applies when (10 x 3) mm busbars are used.

packaging type:

Box

pole no:

12

rated current:

96 A

rated surge voltage iii 3:

6 kV

solid conductor:

0.5 4 mm / 20 12 AWG

solid conductor push in termination:

0.5 4 mm / 20 12 AWG

stranded conductor:

0.5 4 mm / 20 12 AWG

strip length:

11 mm / 0.43 inch

weight:

35.708 g

width:

75 mm / 2.953 inch

wiring direction:

Front-entry wiring
