(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +105 C
locking of plug in connection:
Screw flange
material group:
I
material of the additional spring for socket contact:
Chrome nickel spring steel (CrNi)
mismating protection:
Yes
nominal voltage ii 2:
1000 V
nominal voltage iii 3:
800 V
pin spacing:
7.62 mm / 0.3 inch
pole no:
6
rated current:
41 A
rated current csa use group c:
41 A
rated current ul use group c:
42 A
rated surge voltage ii 2:
8 kV
rated surge voltage iii 2:
8 kV
rated surge voltage iii 3:
8 kV
rated voltage csa use group c:
600 V
rated voltage iii 2:
1000 V
rated voltage ul use group c:
600 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
