Wago

WAGO 831-3207

(No reviews yet) Write a Review
SKU:
831-3207
MPN:
831-3207
Condition:
New
actuation type:
Operating tool
approvals per:
UL 1059
clamping spring material:
Chrome nickel spring steel (CrNi)
color:
Light gray
conductor entry direction to mating direction:
0
connection technology:
Push-in CAGE CLAMP
connection technology 2:
Quick-connect/solder contact
connector connection type:
For conductor
contact material:
Electrolytic copper (ECu)
contact plating:
Tin-plated
contact type pluggable connector:
Male connector/plug
country of origin sales organisation germany:
PL
depth:
46 mm / 1.811 inch
fine stranded conductor:
0.5 10 mm / 20 8 AWG
fine stranded conductor with insulated ferrule:
0.5 6 mm
fine stranded conductor with uninsulated ferrule:
0.5 6 mm
fire load:
0.000 MJ
flammability class per ul94:
V0
height:
27.5 mm / 1.083 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +105 C
locking of plug in connection:
Without
material group:
I
mismating protection:
Yes
nominal voltage ii 2:
1000 V
nominal voltage iii 3:
800 V
packaging type:
Box
pin spacing:
7.62 mm / 0.3 inch
pole no:
7
rated current:
41 A
rated current csa use group c:
41 A
rated current ul use group c:
42 A
rated surge voltage ii 2:
8 kV
rated surge voltage iii 2:
8 kV
rated surge voltage iii 3:
8 kV
rated voltage csa use group c:
600 V
rated voltage iii 2:
1000 V
rated voltage ul use group c:
600 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
solid conductor:
0.5 10 mm / 20 8 AWG
strip length:
13 15 mm / 0.51 0.59 inch
weight:
45.880 g
width:
55.22 mm / 2.174 inch
  • Wago 831-3207
  • Wago 831-3207
  • Wago 831-3207
$15.93

Description

1-conductor male connector; Push-in CAGE CLAMP; 10 mm²; Pin spacing 7.62 mm; 7-pole; 100% protected against mismating; 10,00 mm²; light gray.

The WAGO component equivalent to 8313207 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and maintenance-free connections. This component is known for its high quality, durability, and ease of installation, making it a preferred choice for various industrial applications. It meets stringent industry standards and is compatible with a wide range of systems, offering flexibility and performance in demanding environments.
