1-conductor male connector 100% protected against mismating, light gray
- Intuitive and tool-free lever actuation
- Universal connection for all conductor types
- Push-in terminations of solid and ferruled conductors
- Test slot 0 and 90 to conductor entry
- 100% protected against mismating
- Coding via coding fingers
The WAGO component equivalent to 8321203333000 is a specific part or module used in electrical and automation systems. It is designed to meet particular technical specifications and standards, ensuring compatibility and functionality within WAGO's range of products. This component plays a crucial role in various applications, providing reliable performance and integration capabilities for efficient system operations.
- actuation type:
- Lever
- approvals per:
- CSA
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- color:
- Light gray
- color of actuator:
- Orange
- conductor entry direction to mating direction:
- 0
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For conductor
- contact material:
- Electrolytic copper (ECu)
- contact plating:
- Silver-plated
- contact type pluggable connector:
- Male connector/plug
- country of origin sales organisation germany:
- DE
- depth:
- 95.6 mm / 3.764 inch
- fine stranded conductor:
- 0.75 25 mm / 18 4 AWG
- fine stranded conductor with insulated ferrule:
- 0.75 16 mm
- fine stranded conductor with uninsulated ferrule:
- 0.75 16 mm
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 29.1 mm / 1.146 inch
- insulation material:
- Polybutylene terephthalate (PBT)
- legend ratings:
- (III / 2) Overvoltage category III / Pollution degree 2
- limit temperature range:
- -60 +120 C
- locking of plug in connection:
- Without
- material group:
- I
- mismating protection:
- Yes
- nominal voltage ii 2:
- 1000 V
- nominal voltage iii 3:
- 1000 V
- packaging type:
- Box
- pin spacing:
- 10.16 mm / 0.4 inch
- pole no:
- 3
- rated current:
- 76 A
- rated current csa use group b:
- 66 A
- rated current csa use group c:
- 66 A
- rated current ul 1977:
- 85 A
- rated current ul use group b:
- 66 A
- rated current ul use group c:
- 66 A
- rated surge voltage ii 2:
- 8 kV
- rated surge voltage iii 2:
- 8 kV
- rated surge voltage iii 3:
- 8 kV
- rated voltage csa use group b:
- 600 V
- rated voltage csa use group c:
- 600 V
- rated voltage iii 2:
- 1000 V
- rated voltage ul 1977:
- 600 V
- rated voltage ul use group b:
- 600 V
- rated voltage ul use group c:
- 600 V
- ratings per:
- IEC/EN 60664-1
- safety information 1:
- The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
- solid conductor:
- 0.75 16 mm / 18 4 AWG
- strain relief:
- Strain relief plate
- strip length:
- 18 20 mm / 0.71 0.79 inch
- weight:
- 41.477 g
- weight of insulation material:
- 16.41
- width:
- 31.78 mm / 1.251 inch
