WAGO 855-505/600-1001 Plug-In Current Transformer 600A/5A
Wago
$144.70
PI-CTPRC 600A SRC 5A.
The WAGO 855 series measurement current transformer (CT) with a 600/5A rating and Accuracy Class 1 (Cl.1) supports a maximum burden of 10VA. It features CAGE CLAMP spring connections and is designed for surface or cable mounting with an 85mm width. The transformer is rated for ambient temperatures ranging from -5°C to +50°C and is equivalent to model number 8555056001001.
- accuracy class:
- 1
- conformity marking:
- CE
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- HU
- depth:
- 52 mm / 2.047 inch
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fire load:
- 0.000 MJ
- height:
- 105.25 mm / 4.144 inch
- insulation class:
- E
- mounting type:
- Closed current transformer || Installation on mounting plate || Mounting on round cable
- operating altitude max:
- 1000 m
- overcurrent limiting factor:
- FS5 / FS10 (type dependent: see type plate inscription)
- packaging type:
- Box
- primary rated current:
- 600 A
- rated continuous thermal current icth:
- 1.2 x IN
- rated frequency:
- 50 60 Hz
- rated power sr:
- 10 VA
- rated short time thermal current ith:
- 60 x IN / 1 s (max. 100 kA / 1 s)
- secondary rated current:
- 0.208333333333333
- solid conductor:
- 0.08 4 mm / 28 12 AWG
- standards specifications:
- EN 61869-1 || EN 61869-2 || UL: E356480
- strip length:
- 9 10 mm / 0.35 0.39 inch
- surrounding air temperature operation:
- -5 50 C
- surrounding air temperature storage:
- -25 70 C
- test voltage:
- AC 6 kV: 50 Hz: 1 min
- weight:
- 366.000 g
- width:
- 85 mm / 3.346 inch
