WAGO 855-5101/600-000 Split-Core Current Transformer, 600A Input, 1A Output
Wago
$588.50
Split-core current transformer; Primary rated current: 600 A; Secondary rated current: 1 A; Rated power: 0.5 VA; Accuracy class: 0.5.
The WAGO component equivalent to 8555101600000 is a specific part or module used in electrical and automation systems. This component is designed to meet particular technical specifications and standards, ensuring compatibility and functionality within WAGO's range of products. It is likely used for tasks such as signal processing, control, or connectivity in various industrial applications.
- accuracy class:
- 0.5
- cable length:
- 5 m
- cable type:
- 2 x 0.5 mm: fine-stranded
- color code:
- Brown = S1: blue = S2
- conformity marking:
- CE
- country of origin sales organisation germany:
- NL
- feedthrough for measurement conductor:
- 2 x 42 mm
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V2
- housing material:
- PA 66
- mounting type:
- Split-core current transformer (suspended)
- operating altitude max:
- 2000 m
- packaging type:
- Box
- primary rated current:
- 600 A
- rated continuous thermal current icth:
- 1
- rated frequency:
- 50 60 Hz
- rated power sr:
- 0.5 VA
- rated short time thermal current ith:
- 60 x IN / 1 s
- rated surge current idyn:
- 2.5 x Ith
- relative humidity:
- 5 85 % (without condensation)
- secondary rated current:
- 0.0416666666666667
- standards specifications:
- EN 61869-1 || EN 61869-2
- surrounding air temperature operation:
- -10 55 C
- surrounding air temperature storage:
- -20 70 C
- test voltage:
- AC 3 kV: 50 Hz: 1 min
- weight:
- 790.000 g
