WAGO 857-155 Basic Relay, 60 VDC, 6 A, SPDT, 5 mm x 15 mm, Pack of 20
Wago
$324.40
Basic relay; Nominal input voltage: 60 VDC; 1 changeover contact; Limiting continuous current: 6 A; Module width: 5 mm; Module height: 15 mm.
The WAGO 857 series replacement plug-in basic relay is a single-pole (1P) electromechanical relay with a control voltage of 60Vdc and a single pole double throw (SPDT) contact configuration. It has a rated current of 6A continuous, 3A at 250Vac (AC-15), and 2A at 24Vdc (DC-13). The relay features push-in connections, plug-in mounting, and an IP20 protection rating. It uses Silver-Tin (AgSnO) contacts and is equivalent to model 857155.
- color:
- Orange
- country of origin sales organisation germany:
- CN
- depth:
- 33 mm / 1.299 inch
- fire load:
- 0.031 MJ
- flammability class per ul94:
- V0
- height:
- 48.5 mm / 1.909 inch
- packaging type:
- Box
- weight:
- 1.150 g
- width:
- 0.7 mm / 0.028 inch
