Wago

WAGO 857-364

SKU:

857-364

UPC:

MPN:

857-364

Condition:

New

bounce time typ:

3.5 ms

circuit type:

Mains circuits

connection technology:

Push-in CAGE CLAMP

contact material relay:

AgNi + Au

country of origin sales organisation germany:

DE

depth from upper edge of din rail:

81 mm / 3.189 inch

dielectric strength control load circuit ac 1 min:

3.51 kVrms

dielectric strength open contact ac 1 min:

1 kVrms

drop out time typ:

25 ms

electrical life no resistive load 23 c:

50 x 103 switching operations

fine stranded conductor:

0.34 2.5 mm / 22 14 AWG

fire load:

0.000 MJ

height:

94 mm / 3.701 inch

input voltage range:

-15 +20 %

inrush current resistive max:

(AC) 20 A / 0.02 s

insulation type between adjacent devices of the the same type:

Reinforced insulation (safe isolation)

insulation type control load circuit:

Reinforced insulation (safe isolation)

limiting continuous current:

0.25

mechanical life:

5 x 106 switching operations

mounting type:

DIN-35 rail

nominal input current at un:

8.5 mA

nominal input voltage un:

AC/DC 24 V

note:

To prevent damaging the gold layer, 30 V switching voltages and 50 mA currents must not be exceeded. Higher switching power eventually evaporates the gold layer. The resulting deposits in the housing may reduce service life.To protect the relay coils

number of changeover switchover contacts:

1

operating altitude max:

2000 m

overvoltage category:

III

packaging type:

Box

pollution degree:

2

processing temperature:

-25 +50 C

protection type:

IP20

pull in time typ:

15 ms

rated surge voltage:

4 kV

rated voltage:

300 V

recommended minimum load:

1 V / 1 mA / 1 mW

relative humidity:

5 85 % (no condensation permissible)

solid conductor:

0.34 2.5 mm / 22 14 AWG

standards specifications:

EN 61010-2-201 || EN 61810-1 || EN 61373 || UL 508 || ATEX || IEC Ex

status indicator:

Yellow LED

strip length:

9 10 mm / 0.35 0.39 inch

surrounding air temperature operation at un:

-40 60 C

surrounding air temperature storage:

-40 70 C

switching capacity:

AC-15: 3 A / AC 250 V: DC-13: 2 A / DC 24 V

switching frequency with without load max:

6 min-1 / 180 min-1

switching power resistive max:

AC 1500 VA: DC (see load limit curve)

switching voltage max:

AC 250 V

wago basic relay:

857-157

weight:

30.300 g

width:

6 mm / 0.236 inch
