WAGO 858-507 Pack of 5

(No reviews yet) Write a Review

Write a Review

WAGO 858-507 Pack of 5

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

858-507

UPC:

MPN:

858-507

Condition:

New

bounce time typ:

4 ms

connection technology:

Push-in CAGE CLAMP

contact material relay:

AgCe

country of origin sales organisation germany:

DE

depth from upper edge of din rail:

73 mm / 2.874 inch

dielectric strength control load circuit ac 1 min:

1.5 kVrms

dielectric strength load load circuit ac 1 min:

1.5 kVrms

dielectric strength open contact ac 1 min:

1 kVrms

drop out time typ:

35 ms

electrical life no resistive load 23 c:

100 x 103 switching operations

fine stranded conductor:

0.34 1.5 mm / 22 16 AWG

fire load:

1.226 MJ

height:

97 mm / 3.819 inch

input voltage range:

-20 +10 %

inrush current resistive max:

(AC) 15 A / 4 s

insulation type adjacent devices:

Reinforced insulation (safe isolation)

insulation type control load circuit:

Basic insulation

insulation type load load circuit:

Basic insulation

limiting continuous current:

0.208333333333333

mechanical life:

20 x 106 switching operations

mounting position:

Horizontal (standing/lying): vertical

mounting type:

DIN-35 rail

nominal input current at un:

10 mA

nominal input voltage un:

AC 115 V

note conductor cross section:

2 x 0.34 2 x 1.5 mm / 1 x 2.5 mm / 2 x 22 2 x 16 AWG

number of changeover switchover contacts:

4

operating altitude max:

2000 m

packaging type:

Box

pollution degree:

2

processing temperature:

-25 +50 C

protection type:

IP20

pull in time typ:

25 ms

rated surge voltage:

2.5 kV

rated voltage:

300 V

recommended minimum load:

12 V / 100 mA

relative humidity:

5 85 %

solid conductor:

0.34 1.5 mm / 22 16 AWG

standards specifications:

EN 61010-2-201 || EN 61810-1 || EN 61373 || UL 508 (max. 50 C)

status indicator:

Red LED || Mechanical

strip length:

9 10 mm / 0.35 0.39 inch

surrounding air temperature operation at un:

-25 70 C

surrounding air temperature storage:

-40 70 C

switching capacity:

AC-15: 1 A / AC 240 V: DC-13: 2 A / DC 24 V

switching power resistive max:

AC 1250 VA: DC (see load limit curve)

switching voltage max:

AC 250 V

wago basic relay:

858-158

weight:

96.700 g

width:

31 mm / 1.22 inch
