Terminal strip (compact block terminal strip); with snap-in mounting feet; for plate thickness 0.6 - 1.2 mm; Fixing hole 3.5 + 0.1 mm 7-pole
Electrical Data
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 24 A
- Legend (ratings): (III / 3) Overvoltage category III / Pollution degree 3
Connection Data
- Connection technology: CAGE CLAMP<sup></sup>
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Solid conductor: 0.08 2.5 mm / 28 12 AWG
- Fine-stranded conductor: 0.08 4 mm / 28 12 AWG
- Strip length: 6 7 mm / 0.24 0.28 inch
- No. of poles: 7
- Total number of connection points: 14
- Total number of potentials: 7
- Number of levels: 1
- Type of wiring: Front-entry wiring
Geometrical Data
- Width: 37.5 mm / 1.476 inch
- Height from the surface: 27.6 mm / 1.087 inch
- Depth: 33.4 mm / 1.315 inch
- Module width: 5 mm / 0.197 inch
Mechanical Data
- Design: horizontal
- Mounting type: Snap-in mounting foot
- Marking level: Side marking
Material Data
- Color: gray
- Fire load: 0.555 MJ
- Weight: 30.167 g
Commercial data
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918481212
- Customs Tariff No.: 85369010000
The WAGO 869 series feed-through terminal strip features a single deck with snap-in mounting feet, accommodating 7 feed-through poles and 14 wires (7 clamps on each side). It supports wire sizes from 0.08mm² to 4mm² (#28AWG to #12AWG) and is rated for a current of 24A. The terminal strip utilizes CAGE CLAMP spring connections and can be mounted on a DIN rail or surface using an accessory snap-in foot mounting. This product is equivalent to the 869157 model.
- actuation type:
- Operating tool
- color:
- Gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth:
- 33.4 mm / 1.315 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.08 1.5 mm / 28 14 AWG
- fire load:
- 0.555 MJ
- flammability class per ul94:
- V0
- height from the surface:
- 27.6 mm / 1.087 inch
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- marking level:
- Side marking
- module width:
- 5 mm / 0.197 inch
- mounting type:
- Snap-in foot
- nominal voltage iii 3:
- 500 V
- packaging type:
- Box
- pole no:
- 7
- rated current:
- 24 A
- rated surge voltage iii 3:
- 6 kV
- safety information 1:
- Max. insulation diameter: 4.4 mm
- solid conductor:
- 0.08 2.5 mm / 28 12 AWG
- strip length:
- 6 7 mm / 0.24 0.28 inch
- weight:
- 30.167 g
- width:
- 37.5 mm / 1.476 inch
- wiring direction:
- Front-entry wiring
