Wago 870-517

WAGO 870-517 Double-Deck Terminal Block, 2.5 mm², 24 A, Gray

Wago
SKU:
870-517
Availability:
Factory stock
$8.32
Condition:
New
Current Stock:
Description
Double-deck terminal block; Ground conductor/through terminal block; PE/N; without marker carrier; Blue conductor entry upper deck; for DIN-rail 35 x 15 and 35 x 7.5; 2.5 mm; CAGE CLAMPp>
Electrical Data
  • Rated voltage (III / 3): 500 V
  • Rated impulse voltage (III / 3): 6 kV
  • Rated current: 24 A
  • Legend (ratings): (III / 3) Overvoltage category III / Pollution degree 3
Connection Data
  • Connection technology: CAGE CLAMP<sup></sup>
  • Actuation type: Operating tool
  • Connectable conductor materials: Copper
  • Solid conductor: 0.08 2.5 mm / 28 12 AWG
  • Fine-stranded conductor: 0.08 4 mm / 28 12 AWG
  • Strip length: 6 7 mm / 0.24 0.28 inch
  • Total number of connection points: 4
  • Total number of potentials: 2
  • Number of levels: 2
  • Type of wiring: Front-entry wiring
Geometrical Data
  • Width: 5 mm / 0.197 inch
  • Height from upper-edge of DIN-35 rail: 40 mm / 1.575 inch
  • Depth: 70 mm / 2.756 inch
Mechanical Data
  • Design: horizontal
  • Type of mounting: DIN-35 rail
  • Potential marking: PE/N
  • Marking level: Side marking
Material Data
  • Color: gray
  • Fire load: 0.164 MJ
  • Weight: 11.310 g
Commercial data
  • Packaging type: BOX
  • Country of origin: DE
  • GTIN: 4044918649681
  • Customs Tariff No.: 85369010000
.

The WAGO 870 X-COM series terminal block is a double-deck, neutral-through and ground/earthing terminal block with side marking slots labeled "PE/N." It features two clamps for neutral and two for protective earth, accommodating wire sizes from 0.08mm² to 4mm² (#28AWG to #12AWG) and supports a rated current of 24A. The terminal block uses CAGE CLAMP spring connections and is designed for mounting on a DIN-35 rail, with a width of 5mm. It is equivalent to model 870517.

Additional Information
actuation type:
Operating tool
color:
Gray
connectable conductor materials:
Copper
connection technology:
CAGE CLAMP
country of origin sales organisation germany:
DE
depth from upper edge of din rail:
40 mm / 1.575 inch
design:
Horizontal type
fine stranded conductor:
0.08 4 mm / 28 12 AWG
fine stranded conductor with insulated ferrule:
0.08 1.5 mm / 28 14 AWG
fire load:
0.164 MJ
flammability class per ul94:
V0
height:
70 mm / 2.756 inch
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
marking level:
Side marking
mounting type:
DIN-35 rail
nominal voltage iii 3:
500 V
packaging type:
Box
rated current:
24 A
rated surge voltage iii 3:
6 kV
ratings per:
IEC/EN 60947-7-1
safety information 1:
Max. insulation diameter: 4.4 mm
solid conductor:
0.08 2.5 mm / 28 12 AWG
strip length:
6 7 mm / 0.24 0.28 inch
weight:
11.310 g
width:
5 mm / 0.197 inch
wiring direction:
Front-entry wiring
