WAGO 870-961 Double-Deck Terminal Block, Through/Through, L/L, Ex e II, DIN Rail 35 x 15 and 35 x 7.5, 2.5 mm², CAGE CLAMP®, Light Gray
Wago
$4.50
Double-deck terminal block; Through/through terminal block; L/L; suitable for Ex e II applications; for DIN-rail 35 x 15 and 35 x 7.5; 2.5 mm²; CAGE CLAMP; 2,50 mm²; light gray.
The WAGO 870 X-COM series feed-through terminal block is a double-deck terminal block with side marking slots, suitable for Ex e II applications. It features "L/L" marking and comes in light gray. The terminal block has two feed-through poles, accommodating four wires with two clamps each, and supports wire sizes from 0.08mm² to 4mm² or #28AWG to #12AWG. It is rated for a current of 18A and utilizes CAGE CLAMP spring connections. The terminal block is designed for mounting on a DIN-35 rail (35 x 15 / 35 x 7.5) and has a width of 5mm, equivalent to model 870961.
- actuation type:
- Operating tool
- color:
- Light gray
- connectable conductor materials:
- Copper
- connection technology:
- CAGE CLAMP
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 40 mm / 1.575 inch
- design:
- Horizontal type
- fine stranded conductor:
- 0.08 4 mm / 28 12 AWG
- fine stranded conductor with insulated ferrule:
- 0.08 1.5 mm / 28 14 AWG
- fire load:
- 0.168 MJ
- flammability class per ul94:
- V0
- height:
- 70 mm / 2.756 inch
- marking level:
- Side marking
- mounting type:
- DIN-35 rail
- packaging type:
- Box
- rated current:
- 18 A
- rated voltage en ex e ii:
- 420 V
- ratings per:
- IEC/EN 60947-7-1
- safety information 1:
- Max. insulation diameter: 4.4 mm
- solid conductor:
- 0.08 2.5 mm / 28 12 AWG
- strip length:
- 6 7 mm / 0.24 0.28 inch
- weight:
- 9.943 g
- width:
- 5 mm / 0.197 inch
- wiring direction:
- Front-entry wiring
