Power tap; 10,00 mm; beige.
The WAGO component equivalent to 8837030 is a specific part used in electrical and automation systems. It is designed to provide reliable and efficient connectivity solutions, ensuring secure and stable connections in various applications. This component is known for its high quality, durability, and ease of use, making it a preferred choice for professionals in the industry. It is compatible with a range of systems and can be integrated seamlessly into existing setups, offering flexibility and performance in demanding environments.
- actuation type:
- Slot screwdriver: (4 x 0.8) mm blade
- color:
- Beige
- connection technology:
- Screw-type connection
- continuous operating temperature:
- -35 +105 C
- country of origin sales organisation germany:
- DE
- fine stranded conductor:
- 0.2 10 mm / 22 8 AWG
- fine stranded conductor with insulated ferrule:
- 0.2 10 mm / 22 8 AWG
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V2
- insulation material:
- Polyamide (PA66)
- nominal cross section:
- 10 mm
- nominal voltage iii 3:
- 1000 V
- packaging type:
- Bag
- rated current:
- 57 A
- rated surge voltage iii 3:
- 6 kV
- solid conductor:
- 0.2 10 mm / 22 8 AWG
- stranded conductor:
- 0.2 10 mm / 24 8 AWG
- strip length:
- 12 mm / 0.47 inch
- tightening torque:
- 1.2 2 Nm
- weight:
- 12.210 g
