Stud terminal block; 35 mm; with 2 stud bolts M6; 35,00 mm; beige.
The WAGO 884 series stud feed-through terminal block is a beige, single-deck component designed for DIN-35 rail mounting, featuring one feed-through pole and two wires with a nominal cross-section of 35mm². It supports a rated current of 125A and includes two M6 stud bolts for mechanical lugs or bars. This terminal block, with a 27mm width, replaces obsolete components 400-490/490-001 and is equivalent to model 8843500.
- actuation type:
- Open-end, ring, socket wrench: 10 mm
- approvals per:
- UL 1059
- bolt thread:
- M6
- clamping range:
- 2.5 50 mm / 14 1/0 AWG
- color:
- Beige
- connectable conductor materials:
- Copper
- connection technology:
- Bolt-type connection
- continuous operating temperature:
- -40 +120 C
- country of origin sales organisation germany:
- DE
- depth from upper edge of din rail:
- 51 mm / 2.008 inch
- din46234 1 cable lug per side:
- 2.5 50 mm
- din46235 1 cable lug per side:
- 6 25 mm
- fire load:
- 0.000 MJ
- flammability class per ul94:
- V0
- height:
- 107 mm / 4.213 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- mounting type:
- DIN-35 rail || Panel mounting
- nominal cross section:
- 35 mm
- nominal voltage iii 3:
- 1000 V
- packaging type:
- Box
- rated current:
- 125 A
- rated current csa use group b:
- 130 A
- rated current csa use group c:
- 130 A
- rated current csa use group d:
- 130 A
- rated current ul use group b:
- 130 A
- rated current ul use group c:
- 130 A
- rated current ul use group d:
- 130 A
- rated surge voltage iii 3:
- 8 kV
- rated voltage csa use group b:
- 1000 V
- rated voltage csa use group c:
- 1000 V
- rated voltage csa use group d:
- 1000 V
- rated voltage ul use group b:
- 1000 V
- rated voltage ul use group c:
- 1000 V
- rated voltage ul use group d:
- 1000 V
- tightening torque:
- 3 6 Nm
- type of cable lugs according to din 46234:
- Cable lugs for solder-free connectionsRing type, without insulating sleeve, for copper conductors
- type of cable lugs according to din 46235:
- Cable lugs for compression connectionsCover plate type for copper conductors
- weight:
- 80.700 g
- width:
- 27 mm / 1.063 inch
