WAGO 890-103 Socket with Strain Relief Housing, 3-Pole, Black
Wago
$5.12
Socket; with strain relief housing; 3-pole; Cod. A; 1,50 mm²; black.
The WAGO component equivalent to 890103 is a specific part or model within the WAGO product line, known for its high-quality electrical interconnection and automation solutions. This component is designed to meet the same specifications and performance standards as the 890103 model, ensuring compatibility and reliability in various applications. WAGO components are widely used in industrial, commercial, and residential settings for their ease of use, durability, and efficiency in electrical installations and automation systems.
- actuation type:
- Operating tool || Push-in
- application:
- General mains applications
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- coding:
- A
- color:
- Black
- conductor entry direction to mating direction:
- 0
- connectable sheathed cable diameter:
- 4.5 10 mm
- connection technology:
- Push-in CAGE CLAMP
- connector connection type:
- For conductor
- contact material:
- Copper or copper alloy (surface-treated)
- contact type pluggable connector:
- Female connector/socket
- continuous operating temperature:
- -35 +85 C
- country of origin sales organisation germany:
- DE
- depth:
- 63.6 mm / 2.504 inch
- fine stranded conductor:
- 0.25 1.5 mm / 22 16 AWG
- fine stranded conductor with ferrule push in termination:
- 0.75 mm / 20 AWG
- fine stranded conductor with insulated ferrule:
- 0.25 0.75 mm / 22 20 AWG
- fine stranded conductor with uninsulated ferrule:
- 0.25 0.75 mm / 22 20 AWG
- fire load:
- 0.024 MJ
- height:
- 14 mm / 0.551 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- locking lever:
- Can be retrofitted
- locking of plug in connection:
- Locking lever
- marking:
- L N
- mating force of a plug in connection:
- Approx. 20 70 N (depending on pole number)
- mismating protection:
- Yes
- nominal cross section:
- 1.5 mm
- nominal voltage iii 3:
- 250 V
- note on continuous operating temperature:
- Insulating parts for temperatures ¤ 105 C
- note on mismating protection:
- All WINSTA components are 100% protected against mismating when:a.) plugging different numbers of polesb.) plugging while rotated 180 c.) plugging while laterally staggeredd.) plugging one pole
- number of mating cycles:
- 200, without resistive load
- packaging type:
- Box
- pin spacing:
- 4.4 mm / 0.173 inch
- pole no:
- 3
- processing temperature:
- -5 +40 C
- protection class:
- IP40
- rated current:
- 16 A
- rated current ul 1977:
- 14 A
- rated surge voltage iii 3:
- 4 kV
- rated voltage ul 1977:
- 600 V
- ratings per:
- IEC/EN 60664-1
- retention force of a plug in connection:
- Locked: > 80 N
- solid conductor:
- 0.25 1.5 mm / 22 16 AWG
- solid conductor push in termination:
- 0.75 1.5 mm / 20 16 AWG
- strain relief:
- Strain relief housing
- stranded conductor:
- 0.25 1 mm / 22 18 AWG
- strip length:
- 9 mm / 0.35 inch
- strip length outer insulation:
- 40 mm
- unmating force of a plug in connection:
- Unlocked: approx. 20 70 N (depending on pole number)
- weight:
- 7.200 g
- width:
- 17.9 mm / 0.705 inch
