Socket for PCBs; straight; 4-pole; Cod. A; white.
The WAGO component equivalent to 890824 is a specific part or module used in electrical and automation systems. It is designed to provide reliable connectivity and functionality within these systems, ensuring efficient performance and integration. This component is likely part of a broader range of products offered by WAGO, a company known for its innovative solutions in electrical interconnection, automation, and interface electronics.
- application:
- General mains applications
- clamping spring material:
- Chrome nickel spring steel (CrNi)
- coding:
- A
- color:
- White
- connector connection type:
- For PCB
- contact material:
- Copper or copper alloy (surface-treated)
- contact type pluggable connector:
- Female connector/socket
- continuous operating temperature:
- -35 +85 C
- country of origin sales organisation germany:
- PL
- depth:
- 12.2 mm / 0.48 inch
- design:
- Straight
- drilled hole diameter with tolerance:
- 1.3 (+0.1) mm
- fire load:
- 0.075 MJ
- height:
- 31.9 mm / 1.256 inch
- height from the surface:
- 28.4 mm / 1.118 inch
- insulation material:
- Polyamide (PA66)
- legend ratings:
- (III / 3) Overvoltage category III / Pollution degree 3
- locking lever:
- Yes
- locking of plug in connection:
- Locking lever
- marking:
- N 2/L 1/L'
- mating direction to the pcb:
- 90
- mating force of a plug in connection:
- Approx. 20 70 N (depending on pole number)
- mismating protection:
- Yes
- nominal voltage iii 3:
- 250 V
- note on continuous operating temperature:
- Insulating parts for temperatures ¤ 105 C
- note on mismating protection:
- All WINSTA components are 100% protected against mismating when:a.) plugging different numbers of polesb.) plugging while rotated 180 c.) plugging while laterally staggeredd.) plugging one pole
- number of mating cycles:
- 200, without resistive load
- number of solder pins per potential:
- 2
- packaging type:
- Box
- pcb contact:
- THT
- pin spacing:
- 4.4 mm / 0.173 inch
- pole no:
- 4
- processing temperature:
- -5 +40 C
- rated current:
- 16 A
- rated current ul 1977:
- 0
- rated surge voltage iii 3:
- 4 kV
- rated voltage ul 1977:
- 600 V
- ratings per:
- IEC/EN 60664-1
- retention force of a plug in connection:
- Locked: > 80 N
- solder pin arrangement:
- 2 in-line solder pins/pole
- solder pin dimensions:
- 1 x 0.8 mm
- solder pin length:
- 3.5 mm
- unmating force of a plug in connection:
- Unlocked: approx. 20 70 N (depending on pole number)
- weight:
- 4.390 g
- width:
- 19.2 mm / 0.756 inch
