WAGO 899-632/101-000

SKU:

899-632/101-000

UPC:

MPN:

Condition:

New

application:

General mains applications

coding:

A

color:

Black

contact material:

Copper or copper alloy (surface-treated)

continuous operating temperature:

-35 +85 C

country of origin sales organisation germany:

DE

depth:

145 mm / 5.709 inch

fire load:

31.157 MJ

height:

30 mm / 1.181 inch

insulation material:

Polyamide (PA66)

internal wiring:

2.5 mm

legend ratings:

(III / 3) Overvoltage category III / Pollution degree 3

locking of plug in connection:

Locking lever

mismating protection:

Yes

mounting type:

Wall, screw mount || Installation on mounting plate

nominal voltage iii 3:

250 V

note on continuous operating temperature:

Insulating parts for temperatures ¤ 105 C

note on mismating protection:

All WINSTA components are 100% protected against mismating when:a.) plugging different numbers of polesb.) plugging while rotated 180 c.) plugging while laterally staggeredd.) plugging one pole

packaging type:

Box

processing temperature:

-5 +40 C

protection class:

IP20: When mated: IP2xC (These compact connectors are not designed for use in open, easily accessible areas!)

rated current:

16 A

rated surge voltage iii 3:

4 kV

ratings per:

IEC/EN 60664-1

weight:

438.010 g

width:

190 mm / 7.48 inch
