Baumer O500.RP-NV1T.72O 11096096 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 8 meters and an actual range of 7.5 meters. It features a polarization filter and suppression of reciprocal influence for enhanced performance. The sensor includes a yellow LED light indicator for operation status and a green LED for power indication. Sensitivity can be adjusted via qTeach. It operates with a wavelength of 630 nm and has an alignment optical axis of less than 1°. The response and release time is less than 0.49 ms. This sensor supports a voltage supply range of 10 to 30 VDC, with a typical current consumption of 30 mA and a maximum of 40 mA. It features both light and dark operating modes, NPN complementary output circuit, and can handle an output current of 100 mA. Safety features include short circuit and reverse polarity protection. The sensor's dimensions are 18 mm in width, 45 mm in height, and 32 mm in depth, with a rectangular plastic housing made of ASA and PMMA. It includes a PMMA front optics and an M12 4-pin connector. Suitable for operating temperatures between -25 to +60 °C, it is IP 67 rated for protection against dust and water ingress.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 7.5 m
- Nominal range Sn:
- 8 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- qTeach
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M12 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
