Datasensing AM6/BP-3A Sensors
Datasensing
$47.58
The Datasensing AM6/BP-3A Sensors are high-performance inductive sensors designed for precision and reliability. Featuring a compact M12 short shielded design, these sensors offer both Normally Open (NO) and Normally Closed (NC) PNP output functions, making them versatile for various applications. With a nominal sensing distance of 4mm and an operating range of 0 to 3.2mm, they are ideal for detecting standard targets of 12x12mm FE360. The sensors are equipped with a 2-meter PVC cable for easy installation and connectivity.
Built to withstand challenging environments, the AM6/BP-3A sensors boast a robust nickel-plated brass housing and an IP67 degree of protection, ensuring durability against dust and water ingress. They operate efficiently within a temperature range of -25°C to +70°C and are protected against short circuits, reverse polarity, impulsive overvoltage, and inductive loads. The sensors also feature a yellow LED indicator for output state visibility and have a switching frequency of 2kHz, ensuring fast and accurate performance.
With a low no-load supply current of ? 10mA and a load current capacity of ? 200mA, these sensors are energy-efficient while maintaining high accuracy with a repeat accuracy of < 5%. The AM6/BP-3A sensors are CE and UR approved, meeting international standards for safety and electromagnetic compatibility. Ideal for industrial automation and control systems, these sensors provide reliable proximity detection with a high degree of mechanical protection against shocks and vibrations.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,2mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,33 / aluminium: 0,4 / brass: 0,5 / stainless steel: 1,05
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NO + NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 60g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
