Datasensing AT1/AP-2A Sensors

The Datasensing AT1/AP-2A Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring an M30 unshielded design with a NO/PNP output, these sensors come equipped with a 2-meter axial cable for easy installation. They offer a nominal sensing distance of 15mm and an operating distance range of 0 to 12.1mm, making them suitable for detecting standard targets of 45x45mm FE360. The sensors are built with a robust nickel-plated brass housing and an active head made of PBT, ensuring durability and resistance to harsh environments. With a switching frequency of 200Hz and an operating voltage range of 10 to 30Vdc, these sensors provide reliable performance with minimal power consumption. They feature comprehensive protection against electrical damages, including short-circuit, reverse polarity, and impulsive overvoltage protection. The sensors are also equipped with a yellow LED indicator for output state visibility and are designed to withstand shocks and vibrations as per IEC standards. The AT1/AP-2A Sensors are IP67 rated, offering excellent mechanical protection against dust and water ingress. They are compatible with a wide range of models, including those with complementary outputs (NO + NC) and ATEX models available on request. The sensors are supplied with two M30x1.5 nuts for secure mounting and are approved with CE and UR certifications, ensuring compliance with international safety standards. Ideal for proximity functions, these sensors are a reliable choice for enhancing automation and efficiency in industrial settings.
