Datasensing AT1/AP-4A8R Sensors
Datasensing
$94.09
The Datasensing AT1/AP-4A8R Inductive Sensor is a high-performance M30 unshielded sensor designed for precise proximity detection. With a nominal sensing distance of 20mm and an operating range of 0 to 16.2mm, it is ideal for various industrial applications. The sensor features a PNP output with a normally open (NO) function, ensuring reliable performance with a switching frequency of 200Hz. It operates efficiently within a voltage range of 10 to 30Vdc, with a low no-load supply current of ? 20mA and a load current capacity of ? 400mA.
Constructed with a durable nickel-plated brass housing and a PBT active head, this sensor is built to withstand harsh environments, offering IP67 mechanical protection. It includes advanced features such as short-circuit, reverse polarity, and impulsive overvoltage protection, along with protection against inductive loads. The sensor's yellow LED indicator provides a clear output state, and it comes with a 10m PVC cable for easy installation.
The AT1/AP-4A8R is designed for standard no-flush mounting and includes two M30x1.5 nuts for secure installation. It is CE and UR approved, with EMC compatibility per IEC 60947-5-2 standards, and is resistant to shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27. Operating efficiently in temperatures ranging from -25°C to +70°C, this sensor is a reliable choice for demanding industrial environments.
- Nominal sensing distance:
- 20mm
- Operanting distance:
- 0 16,2mm
- Standard target:
- 60x60mm FE360
- Correction Factor:
- copper: 0,45 / aluminium: 0,50 / brass: 0,55 / stainless steel: 0,75
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M30 standard no-flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NO
- Switching frequency:
- 200Hz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 20mA
- Load current:
- ? 400mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1V @400mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ?100ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Housing Material:
- Nickel-plated brass
- Connections:
- 10m PVC Cable
- Active Head Material:
- PBT
- Tightening torque:
- 50Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M30
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- 2 nuts M30x1.5
- Dimensions:
- M30 x 1,5 / L = 60mm
- Operating Temperature:
- -25°C +70°C
- Mechanical Protection:
- IP67
