Datasensing CT1/AN-1A Sensors
Datasensing
$176.34
The Datasensing CT1/AN-1A Sensors are designed for precision and reliability in various industrial applications. Featuring a capacitive sensor with a nominal sensing distance of 2 to 15mm, these sensors offer sensitivity adjustment via a convenient trimmer. Housed in durable nickel-plated brass, they provide robust protection with an IP65 rating, ensuring resistance to dust and water ingress. The sensor's axial cable exit is complemented by a 2m PVC cable, facilitating easy installation.
Engineered for optimal performance, the CT1/AN-1A Sensors boast a thermal drift of Sr less than 20% and a repeat accuracy of 10%. The NPN output type with a normally open (NO) function supports a switching frequency of 100Hz, making it suitable for dynamic environments. Operating within a voltage range of 10 to 30Vdc, the sensor maintains a low no-load supply current of ? 8mA and a load current capacity of ? 200mA.
Safety and reliability are paramount, with features such as short-circuit protection with autoreset, reverse polarity protection, and impulsive overvoltage protection. The sensor's LED indicators provide clear status updates, with a green LED for power and a red LED for object detection. Designed to withstand harsh conditions, it operates effectively in temperatures ranging from -25°C to +70°C and is compliant with EMC standards IEC 60947-5-2.
The CT1/AN-1A Sensors come with supplied accessories, including a screwdriver and two M30 nuts, ensuring a seamless setup. With CE and cULus approvals, these sensors are a dependable choice for enhancing automation and control systems.
- Nominal sensing distance:
- 2 15mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 10%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- NPN
- Output Function:
- NO
- Switching frequency:
- 100Hz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 8mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10mA
- Output voltage drop:
- 0,75/1,8V max @ IL=10/200 mA
- Max ripple content:
- ?10%
- LED indicators:
- Green LED power, red LED (object detected)
- Time delay before availability:
- ?100ms
- Short-circuit protection:
- Yes, autoreset
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded
- Weight:
- 260g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC cable
- Active Head Material:
- PBT
- Tightening torque:
- 50Nm
- Operating temperature:
- -25°C +70°C
- Diameter/Dimension:
- M30
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP65
- Supplied Accessories:
- screw driver, 2 x M30 nuts
- Operating Temperature:
- -25°C +70°C (without freeze)
- Mechanical Protection:
- IP65
