Datasensing DGR/00-1B Sensors
Datasensing
$95.81
The Datasensing DGR/00-1B Sensors are designed for optimal performance in challenging environments. These photoelectric sensor receivers boast a nominal sensing distance of 60 meters, with a beam angle of ± 5°, ensuring precise detection. The unit features a robust anodized aluminum housing and a glass active head, providing durability and reliability. With an operating temperature range from -20°C to +60°C, these sensors are suitable for a variety of applications. The sensors are equipped with LED indicators for alignment, operating voltage, alarm, and output state, allowing for easy monitoring and adjustments. They offer both AC and DC operating voltage options, along with relay output and alarm output capabilities. The double timer with independent adjustments and sensitivity adjustment features enhance their versatility. These sensors can be conveniently mounted on panels and are IP68 rated, making them ideal for use in harsh environments. The DGR/00-1B Sensors are CE approved and conform to EMC directives, ensuring compliance and safety.
- Nominal sensing distance:
- 60m
- Beam angle:
- ± 5°
- Function Principle:
- Receiver
- Optic position:
- Axial
- Operating Voltage:
- from UR control unit
- Emission:
- Infrared
- Interference to external light:
- 20000 lux
- Housing Material:
- Anodized alluminium
- Connections:
- 10m PVC cable
- Active Head Material:
- glass
- Diameter/Dimension:
- Ø 10mm
- Approvals:
- CE
- EMC compatibility:
- Conforming with EMC directive according with EN60947-5-2
- Degree of protection:
- IP67
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
