Datasensing FAI5/BN-0E Sensors
Datasensing
$63.50
The Datasensing FAI5/BN-0E Sensors offer a comprehensive solution for precise detection needs. Designed with a complete range of M18 sensors, they operate efficiently within a 10...30 Vdc power supply. These sensors feature both axial and radial optics with a flat surface, making them versatile for various applications. The retro-reflective models are particularly adept at detecting transparent objects, thanks to their red emission and IP67 protection degree, ensuring durability in challenging environments.
Constructed with either metallic or plastic housing, these sensors provide flexibility in installation and application. They come equipped with sensitivity adjustment options, allowing for fine-tuning to meet specific requirements. The sensors boast total protection against any type of electric damages, ensuring reliable performance and longevity. They are CE and cULus listed, affirming their compliance with international safety standards.
Key specifications include a nominal sensing distance of 200mm, a thermal drift of Sr at ?10% Sr, and a repeat accuracy of 5%. The function principle is based on diffuse reflection for short distances up to 200mm, with an axial optic position. The output type is NPN NO+NC, with a switching frequency of 250Hz and a response time of 2ms. Operating within a voltage range of 10
30VDC, these sensors maintain a no-load supply current of ? 30mA and a load current of ?100mA.
Additional features include short-circuit protection with autoreset, overvoltage, and reverse polarity protection. The sensors emit LED Infrared light at 880nm and are resistant to external light interference up to 3000lux from incandescent lamps and 10000lux from sunlight. With dimensions of M18 x 1 /L =81,6mm and a weight of 30g, they are compact yet robust. The housing material is PBT with a PC plug, and they come with M12 plug connections. Operating temperatures range from -25°C to +70°C, ensuring functionality in various climates. The sensors are supplied with M18 x 1 nuts for easy installation.
- Nominal sensing distance:
- 200mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
