The Datasensing FAI8/BN-0E Sensors offer a comprehensive solution for various sensing applications with their robust M18 design and versatile features. These sensors operate on a 10...30 Vdc power supply and are equipped with both axial and radial optics featuring a flat surface. They are particularly effective in detecting transparent objects thanks to their retro-reflective models with red emission, all while maintaining an IP67 protection degree for reliable performance in harsh environments.
Constructed with either metallic or plastic housing, these sensors provide flexibility in installation and application. The sensitivity adjustment is easily accessible via a trimmer, allowing for precise calibration to suit specific needs. With a nominal sensing distance of 1 meter and a thermal drift of Sr at ?10% Sr, these sensors ensure consistent and accurate detection.
The FAI8/BN-0E Sensors utilize a diffuse reflection principle for long-distance detection, exceeding 600mm, and are optimized for a white target Kodak 90% 400 x 400mm. The optic position is axial, and the output type is NPN NO+NC, offering both normally open and normally closed functions. With a switching frequency of 250Hz and a response time of just 2ms, these sensors are designed for high-speed applications.
Additional features include short-circuit protection with auto-reset, overvoltage, and reverse polarity protection, ensuring durability and longevity. The sensors are equipped with LED indicators for easy status monitoring and are resistant to external light interference up to 3000lux from incandescent lamps and 10000lux from sunlight.
Measuring M18 x 1 with a length of 81.6mm and weighing only 30g, these sensors are compact yet powerful. They are compatible with M12 plug connections and come with supplied accessories such as M18 x 1 nuts and a screwdriver for convenient installation. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing FAI8/BN-0E Sensors are CE and cULus approved, meeting EMC compatibility standards EN 60947-5-2, and are designed to withstand shocks and vibrations as per IEC standards.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
