The Datasensing FAIH/00-2A84 Sensors are high-performance photoelectric sensors designed for precision and reliability. Featuring a nominal sensing distance of 15 meters, these sensors are equipped with a radial 90° optic position and an emitter function principle. The robust M18 housing is constructed from durable PBT and PC materials, ensuring long-lasting performance even in challenging environments. With a switching frequency of 250Hz and a rapid response time of 2ms, these sensors are ideal for fast-paced applications. The sensors operate within a voltage range of 10 to 30VDC and have a no-load supply current of ? 25mA, making them energy-efficient. The LED infrared emission at 880nm ensures accurate detection, while the yellow LED indicator provides a clear power-on status. Designed with reverse polarity protection and EMC compatibility, these sensors meet CE and cULus approvals. The 3-meter PVC cable connection and supplied M18 x 1 nuts facilitate easy installation. With an IP67 mechanical protection rating, these sensors are resistant to dust and water, making them suitable for a wide range of industrial applications. Operating effectively in temperatures from -25°C to +70°C, the Datasensing FAIH/00-2A84 Sensors are engineered to deliver consistent performance without freeze, ensuring reliability in diverse conditions.
- Nominal sensing distance:
- 15m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Radial 90°
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Housing Material:
- PBT / PC plug
- Connections:
- 3m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- nuts M18 x 1
- Dimensions:
- M18 x 1/L=78,5mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
