Datasensing FFR3/0N-1EV5 Sensors
Datasensing
$136.31
The Datasensing FFR3/0N-1EV5 Sensors are high-performance photoelectric sensors designed for precise detection tasks. Featuring an M18 axial diffuse design, these sensors offer a nominal sensing distance of 100mm with adjustable sensitivity through a convenient teach-in function. The NPN L/D selectable output ensures versatile application compatibility, while the robust stainless steel AISI 316L housing provides exceptional durability and protection rated at IP68 and IP69K. With a rapid response time of 1ms and a switching frequency of 500Hz, these sensors are ideal for high-speed operations. The LED indicators provide clear status updates, and the sensor is equipped with short-circuit and reverse polarity protection for enhanced reliability. Operating efficiently within a voltage range of 10 to 30VDC, the FFR3/0N-1EV5 is suitable for diverse environments, withstanding temperatures from -25°C to +80°C. Certified with CE, cULus, and ECOLAB Diversey approvals, this sensor is a reliable choice for industrial applications requiring precise and consistent performance.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 35mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green Stability
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5.000lux (incandescent lamp), 10.000lux (sunlight)
- Housing Material:
- Stainless steel AISI 316L / PA12 plug
- Connections:
- M12 plug
- Active Head Material:
- PA12
- Diameter/Dimension:
- Ø 17,5mm
- Approvals:
- CE cULus ECOLAB Diversey
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Dimensions:
- 17,5/L=83mm
- Operating Temperature:
- - 25°C + 80°C (Without freeze)
- Mechanical Protection:
- IP68, IP69K
- User Manuals:
- View
