Datasensing HER/CP-4F Sensors
Datasensing
$146.64
The Datasensing HER/CP-4F Sensors are advanced photoelectric sensor receivers designed for precision and reliability in industrial applications. Featuring an M8 through beam model, these sensors boast a high switching frequency of 1kHz, ensuring rapid response times of just 500µs. The robust stainless steel housing provides complete protection against electrical damages and environmental factors, with an IP67 protection degree for durability in harsh conditions. Operating on a supply voltage range of 10 to 30 VDC, these sensors are equipped with a PNP NC output type and a nominal sensing distance of 2 meters.
The HER/CP-4F Sensors are engineered with a yellow LED status indicator for easy monitoring and include comprehensive safety features such as short-circuit and reverse polarity protection. With a low no-load supply current of ?45mA and a load current capacity of ?100mA, these sensors are energy-efficient and reliable. The sensors are designed to withstand external light interference up to 3,000 lux from incandescent lamps and 5,000 lux from sunlight, making them suitable for various lighting conditions.
Constructed with a stainless steel AISI 303 housing and PMMA active head material, the sensors are built to endure shocks and vibrations as per IEC standards. The M8 plug 3-pin connection ensures easy installation, and the sensors come with supplied accessories, including M8 x 0.75 nuts. With CE approvals and EMC compatibility with EN 60947-5-2, the Datasensing HER/CP-4F Sensors are a dependable choice for your sensing needs.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Notes:
- (EG=2)
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP NC
- Output Function:
- NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Dimensions:
- M8x0,75/L=49mm
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Dimensions:
- M8x0,75/L=54mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
