Datasensing LTB/0N-0C Sensors
Datasensing
$141.17
The Datasensing LTB/0N-0C Sensors are advanced photoelectric contrast scanners designed for precise detection tasks. Featuring a white light emission, these sensors offer a nominal sensing distance of 12mm with the STF-12 focalizer and 25mm with the SFT-25 focalizer. The sensors are equipped with a sensitivity adjustment and boast a short response time of just 50 µs, making them ideal for high-speed applications. With selectable LO/DO outputs and a robust IP65 protection rating, these sensors ensure reliable performance in various environments. They are fully protected against electrical damages, including short-circuit and reverse polarity protection, and are approved with CE certification. The sensors operate within a voltage range of 10 to 30VDC and feature a low no-load supply current of ? 40mA. The LED indicators provide clear status updates, with a yellow light indicating output status and a green light for power ON. Designed with a durable PBT housing and PMMA active head material, the sensors are built to withstand operating temperatures from -5°C to +55°C. The package includes M18 x 1 nuts, with additional focalizers available for separate purchase.
- Nominal sensing distance:
- 12mm (with STF-12) 25mm (with SFT-25)
- Thermal drift of Sr:
- ? 10%
- Spot dimension:
- Ø 1mm (with STF-12) Ø 0,8mm (with SFT-25)
- Function Principle:
- Contrast mark detection
- Notes:
- white target Kodak 90% 100 x 100mm
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 10Khz
- Response time:
- 50 µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 40mA
- Load current:
- ?100mA
- Leakage current:
- ? 10µA
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (output status) Green(powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED white
- Interference to external light:
- 3000 lux (incandescent lamp) 10000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Housing Material:
- PBT
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- -5°C +55°C (without freeze)
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Degree of protection:
- IP65
- Supplied Accessories:
- nuts M18 x 1
- Accessories to be ordered separately:
- Focalizer STF-12 Focalizer STF-25
- Operating Temperature:
- - 5°C + 55° C (Without freeze)
- Mechanical Protection:
- IP65
