Datasensing MS6/00-0A Sensors
Datasensing
$119.81
The Datasensing MS6/00-0A Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection function with a nominal sensing distance of 400mm, these sensors are ideal for medium-distance applications up to 600mm. The sensors are equipped with a 2m axial plastic cable for easy installation and connectivity.
With a wide range of models available, including diffuse, retro-reflective, polarized, through-beam detection, and background suppression, these sensors offer versatility for various industrial applications. The through-beam models boast a high sensing range, while the retro-reflective models utilize red visible polarized light for enhanced accuracy. Additionally, models with right angle optics and fixed distance background suppression are available to suit specific needs.
The MS6/00-0A Sensors are designed with complete protection against electrical damage, including short-circuit protection with auto-reset and overvoltage protection. They operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 40mA and a load current of ?100mA. The sensors feature a selectable NO/NC output function, with a switching frequency of 80Hz and a response time of 6.25ms.
Constructed with durable materials, the housing is made of PBT/PC with a PMMA active head, ensuring robustness and longevity. The sensors are designed to withstand harsh environments, with an operating temperature range of -25°C to +70°C and a degree of protection rated at IP67. They are also compliant with CE and cURus approvals, ensuring high standards of safety and performance.
The MS6/00-0A Sensors are equipped with LED indicators for status output, providing clear visual feedback. They are resistant to external light interference, with a tolerance of up to 3000lux from incandescent lamps and 10000lux from sunlight. The sensors also feature impulsive overvoltage protection and are compatible with EMC standards EN 60947-5-2.
Supplied with M18 x 1 nuts for secure mounting, these sensors are designed for easy integration into existing systems. With a compact size of M18 x 1 /L =78.9mm and a weight of 70g, they offer a reliable and efficient solution for a wide range of industrial sensing applications.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 40mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
